Astm A35 Carbon Steel Pipe

API 5L seamless steel pipe is a seamless steel pipe for pipeline steel--API 5L seamless steel pipe for pipeline steel, seamless steel pipe, pipeline steel material: GR.B, X42, X46, 52, X56, X60, X65, X70. Pipeline pipe is used to transport oil, gas and water extracted from the ground to oil and gas industrial enterprises through pipeline pipes. Pipeline pipes include seamless pipes and welded steel pipes, and their pipe ends include flat ends, threaded ends and socket ends; their connection methods include welding, coupling connection, socket connection, etc.

Contact Now E-Mail Telephone WhatsApp

Product Details

With the development of API 5L seamless steel pipe technology and the advancement of forming and technology, the application scope of API 5L seamless steel pipe is gradually expanding, especially in API 5L large-diameter seamless steel pipe. The advantages are more obvious. Coupled with the cost factor, API 5L seamless steel pipe has occupied a dominant position in the field of pipeline steel pipes. The development of API 5L seamless steel pipe. In 2004, the export of seamless pipes was about 100,000 tons, and the steel grades included GR.B, X42, X46, 52, X56, X60, X65, X70,
Astm A35 Carbon Steel Pipe

Product parameters

API 5L oil pipeline steel pipe:

(1) Standard: API5L ASTM ASME B36.10. DIN

(2) Material: API5LGr.B A106Gr.B, A105Gr.B, A53Gr.B, A243WPB, etc.

(3) Outer diameter: 13.7mm-1219.8mm

(4) Wall thickness: 2.11mm-100mm

(5) Length: 5.8m, 6m, 11.6m, 11.8m, 12m fixed length

(6) Packaging: spray painting, bevel, pipe cap, galvanized steel strapping, yellow lifting strap, overall woven bg packaging.

(7) API 5LGR.B pipeline steel seamless steel pipe.

API 5L Seamless Steel Tube Performance Tables
material	GR.B	X-42
Outer Diameter Tolerance	1%	1%
Wall Thickness Tolerance	12.5%	12.5%
Length Tolerance	2%	2%
Bevel angle	35°	35°
Bevel Blunt Edge Size	1/16 inch ± 1/32 inch	1/16 inch ± 1/32 inch
Test water pressure and holding time	1070psig 5 seconds	1070psig 5 seconds
tensile strength	60000=414mpa	60000=414mpa
yield strength	35000=241mpa	42000=290mpa
elongation	230%	230%
Contents of steel stamp marking	KSLAPi 5LSeamless steel pipe 6#SCH4013560
straightness	2%	2%
Weld Inspection Methods	100% X-ray	100% X-ray
non-flared	be	be
Plastic end caps	be	be
Tube inner and outer coating	un-	un-
Weight measurement method	checkweighing	checkweighing
